Nilight 50003R Automotive Set 5-Pin 30/40A 12V SPDT with Interlocking Relay Socket and Wiring Harness-5 Pack, 2 Years Warranty
$14.01
Automotive engineering, vehicle component Sold by Amazon Fulfilled by Amazon

Nilight 50003R Automotive Set 5-Pin 30/40A 12V SPDT with Interlocking Relay Socket and Wiring Harness-5 Pack, 2 Years Warranty

GHS 305 delivered to Accra est.

Estimate for one unit, air shipping. Final total is confirmed at checkout.

Product arrives warehouse Sep 10, 2026. Products ship from our warehouse every Friday. Delivered to you by Sep 22, 2026.

Quantity
1
Color

About this item

Nilight 12V 5-Pin Relay with 5-Pin Harness Socket (30A NC/40A NO) A relay is an electrically operated switch which use a smaller current to control a larger current. Functions as automatic adjustment, safety protection and conversion circuit. Specification Contact Capacity Normal Switching Capacity (Resistance load) NO (Normal Open) 40A 14VDC NC (Normal Closed) 30A 14VDC Max. Switching Current 40A Max. Switching Voltage 30VDC Max. Switching Power 560W Performance Parameter Contact Material: Silver Alloy Contact Resistance: 50mΩ Max. Operate Time (at nominal volt.): 10 msec. Max. Release Time (at nominal volt.): 5 msec. Max. Insulation Resistance: 100MΩ Min. (DC500V) Initial Dielectric Strength: - Between open contacts: AC500V, 50/60 Hz 1Min. - Between coil and contact: AC500V, 50/60 Hz 1Min. Vibration Resistance: - Functional: 10 ~ 55Hz at double amplitude of 1. 5 mm - Destructive: 10 ~ 55Hz at double amplitude of 1. 5 mm Shock Resistance: - Functional: 20G Min. - Destructive: 100G Min. Endurance (operations) Mechanical (at 7, 200 ops. /h): 10, 000, 000 Electrical (at 600 ops. /h): 100, 000 Ambient Temperature: -40 degree Celsius ~ +125 Degree Celsius (no condensation) Application Pre-wired relay with harness socket, compatible with almost all kinds of automotive devices that use a 12V DC power source. Widely used for car lights, fog lamps, headlights, seat warming, windshield wiper, starter, fans, speakers, traction control systems, etc.

Condition

New
$14.01

Nilight 50003R Automotive Set 5-Pin 30/40A 12V SPDT with Interlocking Relay Socket and Wiring Harness-5 Pack, 2 Years Warranty · x1
